Applications: ideal for high and large space (H: 4-30m) that needs cooling and heating with uniform airflow and temp distribution.
Model: AirTS-K-I, AirTS-K-II
Function: cooling, heating
Cold and hot source: cold water (7-12℃)/hot water (40-90℃)
Control mode: wireless control, variable frequency, auto monitoring
Quality Assurance
Stable and Durable.
After-sales Service
24H Online.
Recirculated Air Heating and Cooling Unit Working Principle
When hot/cold water or stream passes the equipment, the efficient heat exchanger in the equipment is used to achieve rapid heating/cooling of the air.
The large wind pressure axial flow fan installed on the top is used to forcedly press the hot/cold air down. Then the air is subject to pressure boost twice through the silencer sponge and the lower trapezoidal convergence, swirls out from the nozzle through the guide vane and is distributed throughout the space from top to down.
Features
By adjusting wind speed and air outlet angle, it achieves comfortable cooling or heating environment
Supply air angle stepless regulation
Utilize axial fan to efficiently recover heat from the top space, reducing heat/cool loss from the roof, achieving energy-saving effects
The fan is installed below the air exchanger to control noise level (<60 dB)
The special designed square-shaped type air exchanger prevent the leakage of condensate water
The complex designed air exchanger, 1.5 times exchange area than others, takes significant heating efficiency
Long air supply distance, high hot/cold air volume
4 sides return air structure, installed on the roof, require smaller installation space
Function: cooling, heating
Recirculated Air Heating and Cooling Unit Functions
Fall prevention warning monitoring
Working data collection and analysis
Variable air volume and water volume
Wireless intelligent control
Filter net self-cleaning
Circulating air
Support full AirTS products linkage control
Light breeze air supply
AirTS top unit
High and large space air conditioner lifted on the roof
It achieves hot/cold air from the air exchanger in the equipment
It distributes the hot/cold air by means of efficient air distributor, which eliminates the undesirable indoor temp layers
Comfortable cooling or heating environment without wind feeling sense
Looking for a reliable solution to heat or cool large indoor spaces? Contact AirTS today to receive a customized plan and professional advice tailored to your facility.
Specification
Recirculated Air Heating and Cooling Unit | |||
Model | AirTS-K-I | AirTS-K-II | |
Rotating speed of fan | r/min | 0~900 | 0~860 |
Standard circulating air volume | m³/h | 0~6900 | 0~10100 |
Voltage | V | 380±5% | 380±5% |
Electric power | kW | 0~0.85 | 0~1.80 |
Current | A | 0~1.65 | 0~3.60 |
Suitable installation height | m | 4~15 | 4~23 |
Control mode | VAV stepless regulation | VAV stepless regulation | |
Noise | dB | <60 | <60 |
Dimension | |||
Model | AirTS-K-I | AirTS-K-II | |
A | mm | 900 | 1100 |
B | mm | 1250 | 1442 |
C | mm | 735 | 920 |
E | mm | 100 | 100 |
F | mm | 95 | 95 |
G | mm | 480 | 568 |
H | mm | 765 | 935 |
J | mm | 660 | 789 |
K | mm | 890 | 1032 |
L | mm | 1050 | 1292 |
M (internal thread) | mm | DN40 | DN50 |
N (external thread) | mm | DN25 | DN32 |
Weight | kg | 160 | 235 |
Water volume | L | 10 | 13.2 |
Application
Our Recirculated Air Heating and Cooling Units provide efficient climate control for large indoor spaces. Using hot water (40–90°C) or cold water (7–12°C), the system quickly adjusts temperature while the high-pressure axial fan ensures air reaches the floor evenly. Secondary pressurization technology eliminates temperature dead zones, maintaining comfort and energy efficiency across workshops, warehouses, exhibition halls, and greenhouses.
The Recirculated Air Heating and Cooling Unit is suitable for a variety of environments where effective management of the indoor climate is required, which not only improves user comfort, but also helps reduce energy costs and improves operational efficiency.
Commercial buildings: such as office buildings, shopping malls, hotels, etc., which usually need to maintain a comfortable indoor temperature throughout the year. Recirculating air heating and cooling units can adjust the indoor climate according to seasonal changes.
Industrial facilities: In some manufacturing plants or warehouses, maintaining a suitable temperature in the work area is essential to ensure production efficiency and employee comfort.
Factory Workshops: Maintain stable temperatures for production environments.
Warehouses & Logistics Centers: Protect goods from temperature fluctuations.
Exhibition Halls & Sports Facilities: Ensure comfortable conditions for visitors.
Agricultural Greenhouses: Provide optimal temperature for plant growth.
Public facilities: such as schools, hospitals, gymnasiums, etc., these places have a large flow of people and have high requirements for air quality and temperature control.
Special environments: such as data centers, where a large number of servers generate a lot of heat and require effective cooling solutions to ensure the normal operation of the equipment.
Energy saving and high efficiency: By recycling indoor air instead of relying entirely on external fresh air, energy consumption is reduced and the energy efficiency ratio of the system is improved.
Energy Efficient: Precision temperature control automatically adjusts airflow, achieving up to 45% energy savings.
Smart Control: Equipped with a wireless touchscreen system for easy operation and remote monitoring.
Durable & Reliable: Built with high-quality components to ensure long-term, stable operation.
Improving air quality: Although it mainly deals with recirculated air, modern devices are usually equipped with filters to remove particulate matter and pollutants in the air, thereby improving indoor air quality.
Stable temperature control: It can quickly respond to changes in indoor and outdoor temperatures, maintain a stable indoor ambient temperature, and provide users with a comfortable experience.
Flexible installation: Depending on your needs, the Recirculated Air Heating and Cooling Unit can be configured in different ways, either as a standalone system or integrated into an existing HVAC system.
Easy Installation: Designed for rapid deployment to minimize on-site construction time.
Low Maintenance: Modular design allows for easy cleaning and component replacement, reducing upkeep costs.
After-Sales Support: 24/7 online technical assistance ensures worry-free operation.
A1: Yes, it is designed for ceiling heights from 4 to 30 meters, ensuring air reaches the floor efficiently.
A2: Precision temperature control automatically adjusts airflow volume, achieving up to 45% energy savings.
A3: No. The modular design allows quick installation and minimal on-site construction time.
A4: Units feature wireless touchscreen control and support remote monitoring for easy operation.
A5: Ideal for factories, warehouses, logistics centers, exhibition halls, sports facilities, and greenhouses.
